設備主要特點

1.電阻焊是靠焊接電流通過工件而工件本身的電阻產生的高溫熱來熔合焊接的，因此可通過調整提高和改變焊接電流的頻率來使焊接過程更加優化，焊接過程控制的更好，從而提高產品的焊接質量。

中頻焊機就是在此原理基礎上研發產生，普通交流工頻焊機的頻率是50HZ或者60HZ，而中頻焊機的頻率是1000HZ，時間控制精度高，功率因數達98%，無電磁感應渦流干擾，焊接質量相對提高很多。

2.但是并非所有工件的焊接電流值都是1000HZ，有些需要更大一些的焊接頻率，有些則需要小一些，我們公司在此基礎上又研發出焊接電流頻率可調可變的性能更優良的VF系列變頻焊機。其原理是通過加有IGBT的脈沖寬度可調的“焊接控制器”及輸出電壓V和變壓器匝數N可調的“焊接變壓器”一起實現焊接頻率可調。

3.然而這兩種焊接都不會根據工件的細微變化自動調整焊接電流的大小，為了滿足汽車，飛機等高端產品對焊接質量的更高需要，我們公司又在以上兩種焊機的基礎上加裝了“動態電阻原理的中頻自適應控制系統”，

該系統以恒流方式控制技術為基礎，根據工件板厚、工件表面污垢及銹蝕程度，操作人員個體差異性等因素的細微變化及焊點的分流等情況，自動調整焊接過程中的每一個焊點的焊接電流，***焊接質量和焊接效果的高度一致性。

4.中頻電源及變頻電源都是由三相電網供電，而不是傳統的工頻交流焊機的兩相供電，不會造成電網的波動，同時對電網自身的波動，電壓的突然升降，適應性也較強。電流輸出更***、更穩定，更節能、更高效。

5.特別適合焊接導電率較高的鋁，銅材料，比較厚的工件，汽車，航天飛機，其他高端產品及行業的焊接。

Main Application and Characteristic

1. Resistance Welding is one kind of welding technology which melt the metal material by the resistance heating energy which is generated by the welding current passing the workpiece itself.Therefore by increase or adjusting the welding current frequency,it can change and improve the welding quality.

Just basing on this theory,we develop the Middle Frequency Inverter DC Welding Machine,its welding current frequency increase to 1000HZ from common 50HZ or 60HZ.

The controlling time precision is much higher, the power factor is more than 98%,without eddy current electromagnetic induction interference, the welding quality is also improved a lot.

2. While not for all the workpiece,the current optimum value is all same as 1000HZ,some need bigger welding frequency,others need less,just because this reason,basing on the Middle Frequency Welding Technology,we also develop VF Series Variable Frequency Welding Machine which welding frequency is adjustable.

The principle is that by the added a IGBT pulse width adjustable "Welding Controller" and the output voltage of V and transformer turns N all adjustable "Welding Transformer" to fulfill the function of adjustable frequency.

3. However, these two kinds of welding methods both can not adjust welding currecnt value of each welding automatically according to the subtle changes of workpiece.

In order to meet much higher request to welding quality,such as for the automotive,aircraft and other high-end products,we develop one kind of “Dynamic Resistance Principle Auto Self Adaptive Control System”.It can install to both MF and VF Welder,by this way they can adjust the welding current automatically basing different product.

This system is based on the constant current mode control technique, according to the workpiece thickness,different dirt surface of workpiece and the corrosion degree,current shunt,the operator’s individual difference factors,such as the subtle changes and solder joints, it can automatically adjust welding current during the welding process of each welding spot,ensure the consistency of the welding quality and effect.

4. Middle Frequency and Variable Frequency Welder are both powered by three-phase power,compared to the traditional AC welder two-phase power supply,will not cause the fluctuation of power supply, also can adapt suddenly lifting voltage strongly.Current output is also more accurate, more stable, more energy saving and more efficient.

5. These kinds of higher technology is specially suitable for welding higher conductive rate of material,such as aluminum,copper,silver,and so on. Also good at welding much more thicker workpiece,automobile,aerospace,and other high request products and industry.

技術參數

Technical Parameter
